Teardown Of An Aircraft Video Symbol Generator - [Adrian Smith] recently scored an avionics module taken from a British Aerospace 1... - https://hackaday.com/2023/06/19/teardown-of-an-aircraft-video-symbol-generator/ #radiationhardening #britishairways #intel8086 #zilogz180 #teardown #avionics #video

Still hacking on my 8086 simulator. I've added the ability to relocate the framebuffer and a stack view.

Assembly programming is good for the soul.

#assembly #assembler #cpp #imgui #intel8086

I've added a framebuffer display and the ability to dump memory to my 8086 simulator.

I'm having a lot of fun working through Casey Muratori's performance aware programming course. It is like a Zachtronics game that breaks the fourth wall. I mean that in a good way.

Check it out: https://www.computerenhance.com/

#performance #assembly #intel8086 #imgui #zachtronics

Reverse-Engineering the Conditional Jump Circuitry in the 8086 Processor - The condition PLA evaluates microcode conditionals.
As simple as a processor’s ins... - https://hackaday.com/2023/01/27/reverse-engineering-the-conditional-jump-circuitry-in-the-8086-processor/ #reverseengineering #microprocessor #intel8086

Our first task in the microprocessor and microcontroller lab was to 🥁🥁🥁….
Add two numbers on the intel 8086 microprocessor
#university #assembly #cse #processor #intel8086

Our professor started off the lecture by giving an example of the Intel 8086’s segmented memory: code, stack, extra and data. It was interesting to see Intel 8086 discussed here, something I recently saw on Mastodon, being taught at university.
cc @codewiz
#university #compsci #cse #Intel8086

Fascinating post by Ken Shirriff on this circuit design.

"The 8086 microprocessor is one of the most important chips ever created [...] I've been reverse-engineering its circuitry by studying its silicon die. One of the most unusual circuits I found is a "bootstrap driver", a way to boost internal signals to improve performance."

https://www.righto.com/2022/11/the-unusual-bootstrap-drivers-inside.html

#Intel #Intel8086 #Microprocessors #Electronics

Fascinating details, including how the arithmetic unit can be used for logic operations.

"The arithmetic logic unit is the heart of a processor: it performs arithmetic operations such as addition and subtraction. It also carries out Boolean logic operations such as bitwise AND and OR as well as also bit shifts and rotates."

http://www.righto.com/2020/08/reverse-engineering-8086s.html

#Intel #Intel8086 #Microprocessors #Engineering #Technology #CPUs

I had fun times routing PCBs in the old days. Routing is more complicated in chips, of course. Post by Ken Shirriff

"While a modern processor might have 15 layers of metal wiring, chips from the 1970s such as the 8086 had just a single layer of metal, making routing a challenge. Similarly, clock signals must be delivered to all parts of the chip to keep it in synchronization."

http://www.righto.com/2020/08/how-8086-processor-handles-power-and.html

#CPUs #Intel #Microprocessors #Engineering #Intel8086 #ComputerHistory #RetroComputing

Ken Shirriff on the implementation of the registers on the Intel 8086. Such dives into early processors are fun and also tell you that modern day processors, despite their higher transistor counts, aren't really all that different on the physical level.

http://www.righto.com/2020/07/the-intel-8086-processors-registers.html

#ComputerHistory #Intel #Intel8086 #Engineering #Technology #ReverseEngineering
